Product Description
This is a 48V standard POE switch, designed and developed independently by SSC Tech to meet the needs of network power supply. It adopts the latest high-speed Ethernet switching chip, ultra-high backplane bandwidth design, and has extremely fast data processing capabilities to improve smooth data transmission performance ,With 8 power supply network ports, 2 RJ45/uplink ports. Among them, all RJ45 ports support network cable power supply.
it’s suitable for Hikvision,DAHUA and other brands with IEEE802.333af/at PoE Devices(PD)
Support EXTEND mode, Max Network Cable length to 250 meters
Product Application Scheme
POE Application Scheme
Non POE Application Scheme
NOTE: When VLAN Extend mode enable,the Max bandwidth for the Network ports (1-8 ) will be reduced to 10Mbps for each one, Transmission distance will reach 250M on this model. Please check your IP CAMERA’s bit stream setting. We recommend the value does not over 8Mbps(8192Kbps). (The up-link is not affected, it will always working at 100Mbps max speed) 10/100Mbps Midspan Mode-B Unsolicited Power (1,2+/3,6-) Compatible IEEE 802.3af/at, Per port Max 25Watt Wall Mount .
WARM TIPS: (If you change to the VLAN Extend mode, the Max allowable Network Cable length will increased to 250 meters. So we use 48V power adapter. This will avoids the power loss over the long distances, and will make sure the PoE IP Camera working.)
(Please select the consumption according your device power , In order to ensure device stable running, the total power consumption should not exceed 25 watt of the power supply)
If the parameters of your camera are “12V/PoE” , Select this 48V PoE Switch with confidence please，it’s suitable for your cameras.
Product Features
FUNCTION SPECIFICATION
All Port: The transmission rate of 1-8 Fast Ethernet port is 10/100Mbps (12+, 36-) and 2 uplink 10/100Mbps transmission rate Fast Ethernet port.
Security: Independent port and function of current protection
CableType: 3 types and more than 3 types of twisted pair for 10BaseT(No support for
power supply); 5types and more than5 types of twisted pair for 100Base-TX100Base-TX.
Software specification
Switch Capacity: 2.0G
Exchange mode: store-and-forward
Rate of data signalling: 1-8 port 10/100Mbps and 2 UPlink port 10/100Mbps（Half-duplex mode)
Standards compliance: IEEE802.3AF/AT
MAC address space: 8K
Working Environment
Mechanical Dimension : 191mm (L)×141mm(W) ×44mm(H)
Input Power: AC220-AC240 V / 120W
Ambient temperature: Operating Temperature 0℃ to 40℃ / Storage Temperature -40℃ to 70℃
Product Show
What is Included
1. 4CH/8CH/16CH PoE switch x1
2. AC Power Cable x1
