Ulefone Armor 9 Thermal Camera Rugged Phone Android 10 Helio P90 Octa-core 8GB+128GB Mobile Phone 6600mAh 64MP Camera Smartphone
Ulefone ARMOR 9 |
OS:Android 10 Thermal Imaging Camera |
CPU: Helio P90(MT6779) Display :6.3-inch FHD+ |
Battery:6600mAhRAM+ROM: 8GB+128GB |
Rear Camera:64MP+5MP(Secondary camera for the FLIR thermal imaging function)+2MP |
WIFI: 802.11 a/ac/b/g/n（2.4G+5G） |
Bluetooth:V2.1+EDR, V3.0+HS, V4.2+HS, V5.0 |
Sensor:Acceleration Sensor, G-sensor, P-sensor, L-sensor, E-compass, Gyroscope,NFC, pedometer, coulombmeter |
2G:GSM: B2/3/5/8CDMA 1X: BC0/BC13G:WCDMA: B1/2/4/5/8/19 TDSCDMA: B34/B39CDMA EVDO: BC0/BC14G:LTE-FDD: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B/66LTE-TDD: B34/38/39/40/41If you don’t know whether our phone can be used in your country, please click here: About Network bandsIf you have any other questions, please click here to understand, if not resolved, please consult customer service, thank you for your understanding and support |
Ulefone Armor 9’s Specification | |
Product Size: | 168.2*82*15mm |
Product Weight | (phone)/(phone+accessories) |
General | |
Material | TPU+10%GF+PC |
Color | Black |
Power Adapter | 9V/2A (18W fast charge) |
System | |
OS | Android 10 |
CPU | Helio P90(MT6779) |
CPU Core | Octa-core 64-bit 2.2GHz |
GPU | IMG 9XM-HP8@970MHz |
Language | Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese |
Storage | |
RAM | 8GB |
ROM | 128GB |
Memory Card | Yes |
Max. Expansion Supported | 2TB |
Display | |
Screen Size | 6.3-inch FHD+ |
Screen Resolution | 1080*2340 |
Multi-touch | 5 |
Camera | |
Back Camera Pixel | 64MP+5MP(Secondary camera for the FLIR thermal imaging function)+2MP |
Front Camera Pixel | 8MP |
Flash | Four Rear flash |
Video Recording Resolution | 1080P/4K Recording |
Touch Focus | Support |
Thermal Imaging Camera | |
Thermal Imaging Module | FLIR Lepton 2.5, 80X60, 50° HFOV, radiometric |
Sensor Technology | Uncooled VOx microbolometer |
Effective Frame Rate | 8.6 Hz (commercial application exportable) |
Input Clock | 25-MHz nominal, CMOS IO Voltage Levels |
Output Format | User-selectable 14-bit, 8-bit (AGC applied), or 24-bit RGB (AGC and colorization applied) |
Pixel Size | 17 µm |
Scene Dynamic Range | ‘-10-140 °C (high gain); up to 400°C (low gain) typical |
Spectral Range | Longwave infrared, 8 µm to 14 µm |
Temperature Compensation | Automatic. Output image independent of camera temperature. |
Thermal Sensitivity | <50 mK (0.050° C) |
Video Data Interface | Video over SPI |
Non-Operating Temperature Range | ‘-40 °C to +80 °C |
Optimum Temperature Range | ‘-10°C to +80°C |
Shock | 1500 G @ 0.4 ms |
Array format | 80 × 60, progressive scan |
FOV – Diagonal | 63.5° |
FOV – Horizontal | 50° (nominal) |
Image Optimization | Factory configured and fully automated |
Non-Uniformity Correction (NUC) | Automatic with shutter |
Solar protection | Integral |
Input Supply Voltage | 2.8 V, 1.2 V, 2.5 V to 3.1 V IO |
Power Dissipation | 150 mW (operating), 650 mW (during shutter event), 4 mW (standby) |
MyFLIR Application | |
Features | |
Spot Meters | 3-moveable |
ROI | Whole image and rectangle (resizable) |
Min, Max, Average | |
MSX | Yes |
Visible only | Yes |
Alignment Tool | Yes |
Save Image | Photo, Video, Time-lapse, YouTube Live |
Radiometric Jpeg | Yes |
FLIR Tools® compatable | Yes |
Reporting | Yes |
Recall Image and video | Yes |
Span and Level adjustment | Yes |
Span and Level Lock | Yes |
Color Palettes | Yes, 9 |
Temperature Scale | Yes, fixed, and customizable |
Help Menu | Yes, hold icon for description or use guided menu |
Network | |
Cellular | 2G/3G/4G |
Band Details | 2G: GSM: B2/3/5/8 CDMA 1X: BC0/BC1 3G: WCDMA: B1/2/4/5/8/19 TDSCDMA: B34/B39 CDMA EVDO: BC0/BC1 4G: LTE-FDD: B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28A/28B/66 LTE-TDD: B34/38/39/40/41 |
Network Conversation | Dual sim dual standby |
WLAN | 802.11 a/ac/b/g/n（2.4G+5G） |
SIM Card Type | Type 1: Nano sim*1 + Nano sim*1 Type 2: Nano sim*1+ TF card |
Navigation | GPS+GLONASS+北斗+Galileo |
NFC | Yes |
HiFi | FS1860U |
Bluetooth Version | V2.1+EDR, V3.0+HS, V4.2+HS, V5.0 |
Power | |
Capacity | 6600mAh |
Watt Hours Per Battery | 25.4Wh |
Standby Time | 510H |
Talk Time | 25H |
Battery Type | Li-poliymer battery |
Other Features | |
Sensor | Acceleration Sensor, G-sensor, P-sensor, L-sensor, E-compass, Gyroscope, NFC, pedometer, coulombmeter |
Blinking Notification Light | Yes |
Battery Status Light | Yes |
Face Unlock | Yes |
OTG | Yes |
VoLTE | Whether you can use VoLTE depends on the local carriers, because not all of the the local carriers can support this function. |
I/O Interface | Type C 2.0 |
USB | Type C 2.0 |
Audio Jack | 3.5mm |
Software | Normal |
Audio Format Supported | MID/FLAC/MKA/APE/MP3/M4A/AAC/AMR/WAV |
Video Format Supported | MOV/FIV/MKV/AVI/3GP |
Image Format Supported | GIF/JPEG/PNG/BMP |
Text Format Supported | TXT/HTML |
FM Radio | Yes |
Wireless Charge | No |
Certification | CE, FCC, TAC IMEI, MSDS, UN38.3, IEC62133, IP68, IP69K, MIL-STD-810G |
Packing List | 1 x Phone 1 x Battery 1 x AC power charger (100~240V/EU plug) 1 x Data cable (100cm) 1 x Type C to 3.5mm Audio Adapter 1 x Type C to Micro-USB Adapter 1 x SIM needle 1 x Warranty card 1 x Multi-language user manual 1xTempered Glass Screen Protector(Gift * not covered by the warranty ) |
About Power charger
1： We will ship European plug by default.
2: American standard plug only ships from our US warehouse.
3：If you have any questions about the plug of the charger, please contact customer services in advance. Please note that the plug of the charger is not within the scope of After-Sales services.
Thermal Imaging Camera
FLIR® Lepton® with MSX® Technology
The integrated FLIR thermal imaging camera, with MSX technology, on the Ulefone Armor 9 smartphones can detect objects in the scene and create thermal images based on temperature. You will be able to see abnormalities such as heat loss or gain, find animals or people in the dark and you quickly diagnose and resolve problems. A thermal imaging camera can play an important role in electrical and pipeline maintenance, outdoor adventures, emergency rescues and more.
Waterproof 3 in 1 Endoscope* Supported
A Versatile Industrial Inspection Camera
Ulefone Armor 9 features an expansion interface for flexible endoscope on the left. The endoscope is waterproof and comes with semi-rigid cable, you can use the endoscope into many hard-to-reach, narrow and confined places at home or outdoors, such as HVAC, vent pipe, car engines, air conditioners, sofa corners, bathtube pipes, toilets, etc..
MediaTek Helio P90 Processor
Incredible AI Performance
Armor 9 is powered by the most powerful P-Series SoC from MediaTek, Helio P90 which comes with 4.6 times higher performance than Helio P60 & P70 so that you can breeze through any task while maintaining power efficiency. There is almost no lag when loading up apps and switching between most apps. Not only faster AI processing, the versatile also can provide impressive imaging capabilities and unrivalled photography experience.
6600mAh Long-Lasting Battery
Always At Your Service
Spend most of your time outdoors and hope your phone has good stamina? Don’t worry, Ulefone Armor 9 can satisfy your expectation. It packs with a 6600mAh battery inside and it can easily go for approximately two days between charges, and can be fully charged in 3 hours.
Flagship-Level 64MP Camera
Capture Ultra Clarity Images
The super camera system of Armor 9 features Samsung GW1 64MP ultra-high resolution image sensor with Tetracell and integrated 3D HDR technology, let you capture more detailed images and video even in mixed and challenging lighting environment. Four high brightness flash on the back helps to capture the treasure and beauty of the world even under circumstance of insufficient light.
Industry-Leading Durability
*Ulefone Rugged Phone is water and dust resistant. It was tested with a rating of IP68 in an under-controlled laboratory conditions under IEC standard 60529(maxinum depth of 1.5 meters up to 30 minutes). Splash water and dust resistsnce are not permanent conditions, and resistance might decrease as a result of normal wear. Do not attempt to charge a wet Phone; Please refer to the user guide for cleaning and drying instructions. Liquid damage is not covered under warranty.
Android 10
System Wide Dark Theme
Ulefone Armor 9 runs the latest Android 10 out of box, which provides some of the newest ways to control your privacy, customize your phone and get things done. Android 10’s new dark theme uses true black to ease your eyes and keep your battery alive longer.
6.3-inch Waterdrop Screen
All-Round Superior View
Armor 9 equips a sharp and vivid 6.3-inch FHD+ waterdrop screen with 93.9% screen-to-body ratio. Stretch your horizons, and immerse in your favorite videos and games like never before. Along with the high resolution of 1080 x 2340 and wide color gamut, it will offer you outstanding optical performance, everything you see on the phone screen will be as clear as it can be.
Global Frequency Bands
Your Perfect Global Travel Companion
With more frequency bands supported, Ulefone Armor 9 becomes a true global phone, which means you can use 90% areas over the world. Armor 9 adds an extra 4G band — Band 66, which means the network support for North America making it even more appealing.
